Release Notes

This document includes the following sections:

❏System Requirements (Section 1)

❏Compatibility (Section 2)

❏What’s Fixed in Connext 5.0.0 (Section 3)

❏Known Issues (Section 4)

❏Custom Supported Platforms (Section 5)

❏Experimental Features (Section 6)

For an overview of new features, please see the What’s New document (RTI_CoreLibrariesAndUtilities_WhatsNew.pdf).

For more information, visit the RTI Knowledge Base, accessible from https://support.rti.com/, to see sample code, general information on RTI® Connext™ (formerly RTI Data Distribution Ser- vice), performance information, troubleshooting tips, and technical details. By its very nature, the knowledge base is continuously evolving and improving. We hope that you will find it help- ful. If there are questions that you would like to see addressed or comments you would like to share, please send e-mail to support@rti.com. We can only guarantee a response to customers with a current maintenance contract or subscription. You can purchase a maintenance contract or subscription by contacting your local RTI representative (see http://www.rti.com/company/ contact.html), sending an e-mail request to sales@rti.com, or calling +1 (408) 990-7400.

1 System Requirements

1.1Supported Operating Systems

RTI Connext requires a multi-threaded operating system. This section describes the host and tar- get systems supported by Connext.

In this context, a host is the computer on which you will be developing a Connext application. A target is the computer on which the completed application will run. A host installation provides the code generation tool (rtiddsgen), examples and documentation, as well as the header files required to build a Connext application for any architecture. You will also need a target installa- tion, which provides the libraries required to build a Connext application for that particular tar- get architecture.

Table 1.0 lists the platforms available with Connext 5.0.0.

1

			System Requirements
Table 1.0 Platforms Available with Connext 5.0.0
	Platform	Operating System	Reference
	AIX®	AIX 5.3	Table 1.1 on page 4
	INTEGRITY® (target only)	INTEGRITY 5.0.11, 10.0.2	Table 1.2 on page 4
	Linux® (Cell BE™)	Fedora™ 12 (2.6.32 kernel)	Table 1.3 on page 5
		CentOS 5.4, 5.5, 6.0
		Fedora 12 (2.6.32 kernel)
		Fedora 12 (2.6.32 kernel) with gcc 4.5.1
	Linux (Intel®)	Red Hat® Enterprise Linux 5.0-5.2, 5.4, 5.5, 6.0, 6.1	Table 1.4 on page 5
		Red Hat Enterprise Linux 5.2 with Real-Time Extensions
		SUSE® Linux Enterprise Server 10.1 (2.6 kernel)
		Ubuntu® Server 10.04 (2.6 kernel)
		Wind River® Linux 4 (2.6 kernel)
		Freescale™ P2020RDB (2.6.32 kernel)
	Linux (PowerPC®) (target	SELinux (2.6.32 kernel)	Table 1.5 on page 6
	only)	Wind River® Linux 3
		Yellow Dog™ Linux 4.0
	LynxOS® (target only)1	LynxOS 4.0, 4.2, 5.0	Table 1.6 on page 6
	Mac OS®	Mac OS X 10.6	Table 1.7 on page 6
	QNX® (target only)	QNX Neutrino® 6.4.1, 6.5	Table 1.8 on page 6
	Solaris™	Solaris 2.9, 2.10	Table 1.9 on page 7
	VxWorks® (target only)	VxWorks 5.5, 6.3 - 6.9
	VxWorks 653 (target only)	VxWorks 653 2.3	Table 1.10 on page 7
	VxWorks MILS (target only)	VxWorks MILS 2.1.1
		Windows 7 (32-bit and 64-bit Editions)
		Windows 2003 (32-bit and 64-bit Editions)
	Windows®	Windows Server 2008 R2 (64-bit Edition)	Table 1.11 on page 8
		Windows Vista® (32-bit and 64-bit Editions)
		Windows XP Professional (32-bit and 64-bit Editions)
		with Service Pack 2

1.The Java API is not supported on LynxOS platforms in 5.0.0. If your application requires support for Java on LynxOS, please contact your RTI account manager.

Visual Studio® 2005 — Service Pack 1 Redistributable Package MFC Security Update is

Required

❏You must have the Microsoft Visual C++ 2005 Service Pack 1 Redistributable Package MFC Security Update installed on the machine where you are running an application built with the release or debug libraries of the following RTI architecture packages:

•i86Win32VS2005 and x64Win64VS2005, built with dynamic libraries

•i86Win32jdk and x64Win64jdk

•i86Win32dotnet2.0 and x64Win64dotnet2.0

The Microsoft Visual C++ 2005 Service Pack 1 Redistributable Package MFC Security Update can be obtained from the following Microsoft website:

• http://www.microsoft.com/download/en/details.aspx?id=26347

2

System Requirements

Visual Studio 2008 - Service Pack 1 Requirement

❏You must have Visual Studio 2008 Service Pack 1 or the Microsoft Visual C++ 2008 SP1 Redistribution Package installed on the machine where you are running an application built with the release libraries of the following RTI architecture packages:

•i86Win32VS2008 built with dynamic libraries

•x64Win64VS2008 built with dynamic libraries

To run an application built with debug libraries of the above RTI architecture packages, you must have Visual Studio 2008 Service Pack 1 installed.

The Microsoft Visual C++ 2008 Service Pack 1 Redistribution Package can be obtained from the following Microsoft website:

•For x86 architectures:

http://www.microsoft.com/downloads/details.aspx?familyid=A5C84275-3B97- 4AB7-A40D-3802B2AF5FC2&displaylang=en

•For x64 architectures:

http://www.microsoft.com/downloads/details.aspx?FamilyID=ba9257ca-337f- 4b40-8c14-157cfdffee4e&displaylang=en

Visual Studio 2010 - Service Pack 1 Requirement

❏You must have Visual Studio 2010 Service Pack 1 or the Microsoft Visual C++ 2010 SP1 Redistribution Package installed on the machine where you are running an application built with the release libraries of the following RTI architecture packages:

•i86Win32VS2010 built with dynamic libraries

•x64Win64VS2010 built with dynamic libraries

•i86Win32dotnet4.0 and x64Win64dotnet4.0

To run an application built with debug libraries of the above RTI architecture packages, you must have Visual Studio 2010 Service Pack 1 installed.

The Microsoft Visual C++ 2010 Service Pack 1 Redistribution Package can be obtained from the following Microsoft website:

•For x86 architectures: http://www.microsoft.com/download/en/details.aspx?id=5555

•For x64 architectures: http://www.microsoft.com/download/en/details.aspx?id=14632

Note: Additional platforms not listed in this document may be supported through special devel- opment and maintenance agreements. Contact your RTI sales representative for details.

The following tables provide additional details. See the RTI Core Libraries and Utilities User’s Manual and Platform Notes for more information on compilers and linkers.

❏Table 1.1, “AIX Platforms,” on page 1-4

❏Table 1.2, “INTEGRITY Platforms,” on page 1-4

❏Table 1.3, “Linux Platforms on Cell BE CPUs,” on page 1-5

❏Table 1.4, “Linux Platforms on Intel CPUs,” on page 1-5

❏Table 1.5, “Linux Platforms on PowerPC CPUs,” on page 1-6

❏Table 1.6, “LynxOS Platforms,” on page 1-6

❏Table 1.7, “Mac OS Platforms,” on page 1-6

3

System Requirements

❏Table 1.8, “QNX Platforms,” on page 1-6

❏Table 1.9, “Solaris Platforms,” on page 1-7

❏Table 1.10, “VxWorks Target Platforms,” on page 1-7

❏Table 1.11, “Windows Platforms,” on page 1-8

1.2Disk and Memory Usage

Disk usage for a typical host-only installation is approximately 250 MB. Each additional archi- tecture (host or target) requires an additional 75 MB.

We recommend that you have at least 256 MB RAM installed on your host development system. The target requirements are significantly smaller and they depend on the complexity of your application and hardware architecture.

1.3Networking Support

Connext includes full support for pluggable transports. Connext applications can run over vari- ous communication media, such as UDP/IP over Ethernet, and local inter-process shared mem- ory—provided the correct transport plug-ins for the media are installed.

By default, Connext uses the UDP/IPv4 and shared-memory transport plug-ins. The shared memory transport is not supported for VxWorks 5.5.

A built-in IPv6 transport is also available (disabled by default) for these platforms:

❏Linux/Fedora: All platforms except SELinux (2.6.32. kernel)

❏QNX: All platforms

❏Solaris: All platforms

❏VxWorks 6.7 (except ppc405Vx6.6gcc4.1.2), 6.8, 6.9

❏Windows: All platforms

A TCP transport is also available (but is not a built-in transport) for the following platforms:

❏Red Hat Enterprise Linux 5.0-5.2, 5.4, 5.5, 6.0, 6.1; CentOS 5.4, 5.5, 6.0; and Ubuntu 10.04

❏Windows with Visual Studio 2005, 2008, and 2010.

Supported architectures appear on the following pages, followed by Compatibility (Section 2).

Table 1.1 AIX Platforms

	Operating System		CPU	Compiler	RTI Architecture
					Abbreviation
			POWER5 (32-bit mode)	IBM XLC for AIX v9.0	p5AIX5.3xlc9.0
	AIX 5.3			IBM Java 1.6	p5AIX5.3xlc9.0jdk
			POWER5 (64-bit mode)	IBM XLC for AIX v9.0	64p5AIX5.3xlc9.0
				IBM Java 1.6	64p5AIX5.3xlc9.0jdk
Table 1.2 INTEGRITY Platforms

Operating System	CPU	Compiler	IP Stack	RTI Architecture Abbreviation
INTEGRITY 5.0.11	PPC 85xx	multi 4.2.4	GHnet2 IP stack1	ppc85xxInty5.0.11.xes-p2020
INTEGRITY 10.0.22	x86	multi 5.0.6	CHNet IPv4 stack	pentiumInty10.0.2.pcx86

1.Kernel must be built using -lip4 or -lip46.

2.Requires patch_6901.iff from Green Hills Software.

4

				System Requirements
Table 1.3 Linux Platforms on Cell BE CPUs
	Operating System	CPU	Compiler	RTI Architecture
				Abbreviation
	Fedora 12 (2.6.32 kernel)	Cell BE	gcc 4.5.11, glib 2.9	cell64Linux2.6gcc4.5.1

1. Requires a custom version of gcc 4.5.1.

Table 1.4 Linux Platforms on Intel CPUs

	Operating System	CPU	Compiler	RTI Architecture
				Abbreviation
			gcc 4.1.2	i86Linux2.6gcc4.1.2
		x86
			Sun Java Platform Standard	i86Linux2.6gcc4.1.2jdk
	CentOS 5.4, 5.5 (2.6 kernel)		Edition JDK 1.6
			gcc 4.1.2	x64Linux2.6gcc4.1.2
		x64
			Sun Java Platform Standard	x64Linux2.6gcc4.1.2jdk
			Edition JDK 1.6
			gcc 4.4.5	i86Linux2.6gcc4.4.5
		x86
			Sun Java Platform Standard	i86Linux2.6gcc4.4.5jdk
	CentOS 6.0		Edition JDK 1.6
			gcc 4.4.5	x64Linux2.6gcc4.4.5
		x64
			Sun Java Platform Standard	x64Linux2.6gcc4.4.5jdk
			Edition JDK 1.6
	Fedora 12 (2.6 kernel)	x64	gcc 4.4.4	x64Linux2.6gcc4.4.4
	Fedora 12 (2.6.32 kernel) with gcc 4.5.1	x64	gcc 4.5.11	x64Linux2.6gcc4.5.1
			gcc 4.1.1	i86Linux2.6gcc4.1.1
		x86
	Red Hat Enterprise Linux 5.0 (2.6 ker-		Sun Java Platform Standard	i86Linux2.6gcc4.1.1jdk
			Edition JDK 1.6
	nel)
			gcc 4.1.1	x64Linux2.6gcc4.1.1
		x64
			Sun Java Platform Standard	x64Linux2.6gcc4.1.1jdk
			Edition JDK 1.6
			gcc 4.1.2	i86Linux2.6gcc4.1.2
		x86
	Red Hat Enterprise Linux 5.1, 5.2, 5.4,		Sun Java Platform Standard	i86Linux2.6gcc4.1.2jdk
			Edition JDK 1.6
	5.5 (2.6 kernel)		gcc 4.1.2	x64Linux2.6gcc4.1.2
		x64
			Sun Java Platform Standard	x64Linux2.6gcc4.1.2jdk
			Edition JDK 1.6
	Red Hat Enterprise Linux 5.2 with Real-		gcc 4.1.2	i86Linux2.6gcc4.1.2
		x86
			Sun Java Platform Standard
	Time Extensions (2.6 kernel)			i86Linux2.6gcc4.1.2jdk
			Edition JDK 1.6
	Red Hat Enterprise Linux 6.0, 6.1 (2.6	x86	gcc 4.4.5	i86Linux2.6gcc4.4.5
	kernel)	x64	gcc 4.4.5	x64Linux2.6gcc4.4.5
			gcc 4.1.0	i86Suse10.1gcc4.1.0
		x86
	SUSE Linux Enterprise Server 10.1 (2.6		Sun Java Platform Standard	i86Suse10.1gcc4.1.0jdk
			Edition JDK 1.5 and 1.6
	kernel)		gcc 4.1.0	x64Suse10.1gcc4.1.0
		x64
			Sun Java Platform Standard	x64Suse10.1gcc4.1.0jdk
			Edition JDK 1.5 and 1.6

5

				System Requirements
Table 1.4 Linux Platforms on Intel CPUs
	Operating System	CPU	Compiler	RTI Architecture
				Abbreviation
			gcc 4.4.3	i86Linux2.6gcc4.4.3
		x86
			Sun Java Platform Standard	i86Linux2.6gcc4.4.3jdk
	Ubuntu Server 10.04 (LTS)		Edition JDK 1.6
			gcc 4.4.3	x64Linux2.6gcc4.4.3
		x64
			Sun Java Platform Standard	x64Linux2.6gcc4.4.3jdk
			Edition JDK 1.6
	Wind River Linux 4 (2.6 kernel)	x64	gcc 4.4.1	x64WRLinux2.6gcc4.4.1

1. Requires a custom version of gcc 4.5.1.

Table 1.5 Linux Platforms on PowerPC CPUs

	Operating System	CPU	Compiler	RTI Architecture
				Abbreviation
	Freescale P2020RDB (2.6.32	PPC 85xx	Freescale gcc.4.3.74	ppc85xxLinux2.6gcc4.3.2
	kernel)		based on gcc.4.3.2
	SELinux (2.6.32 kernel)	PPC 4xxFP	gcc 4.5.11, glibc 2.9	ppc4xxFPLinux2.6gcc4.5.1
	Wind River Linux 3	PPC 85xx	gcc 4.3.2	ppc85xxWRLinux2.6gcc4.3.2
	Yellow Dog® Linux 4.0	PPC 74xx (such as	gcc 3.3.3	ppc7400Linux2.6gcc3.3.3
	(2.6 kernel)	7410)

1. Requires a custom version of gcc 4.5.1.

Table 1.6 LynxOS Platforms

	Operating	CPU	Compiler	RTI Architecture
	System			Abbreviation
		x86	gcc 3.2.2	i86Lynx4.0.0gcc3.2.2
	LynxOS 4.0	PPC 74xx (such as 7410)	gcc 3.2.2	ppc7400Lynx4.0.0gcc3.2.2
		PPC 604, PPC 7XX (such as 750)	gcc 3.2.2	ppc750Lynx4.0.0gcc3.2.2
	LynxOS 4.2	PPC 74xx (such as 7410)	gcc 3.2.2	ppc7400Lynx4.2.0gcc3.2.2
	LynxOS 5.0	PPC 74xx (such as 7410)	gcc 3.4.3	ppc7400Lynx5.0.0gcc3.4.3
Table 1.7 Mac OS Platforms

	Operating		CPU	Compiler	RTI Architecture
	System				Abbreviation
	Mac OS X		x64	gcc 4.2.1	x64Darwin10gcc4.2.1
				Java SE 1.6 for Mac OS	x64Darwin10gcc4.2.1jdk
Table 1.8 QNX Platforms

	Operating System	CPU	Compiler	RTI Architecture
				Abbreviation
	QNX Neutrino 6.4.1	x86	qcc 4.3.3 with GNU C++ libraries	i86QNX6.4.1qcc_gpp
	QNX Neutrino 6.5	x86	qcc 4.4.2 with GNU C++ libraries	i86QNX6.5qcc_gpp4.4.2

6

								System Requirements
Table 1.9 Solaris Platforms
	Operating	CPU			Compiler			RTI Architecture
	System							Abbreviation
		x86			gcc 3.3.2			i86Sol2.9gcc3.3.2
					Sun Java Platform Standard Edition JDK 1.6			i86Sol2.9jdk
	Solaris 2.9				CC 5.4 (Forte Dev 7, Sun One Studio 7)			sparcSol2.9cc5.4
		UltraSPARC
					Sun Java Platform Standard Edition JDK 1.6			sparcSol2.9jdk
		UltraSPARC			gcc3.4.2			sparcSol2.10gcc3.4.2
					Sun Java Platform Standard Edition JDK 1.5 or 1.6			sparcSol2.10jdk
	Solaris 2.10
		UltraSPARC			gcc3.4.2			sparc64Sol2.10gcc3.4.2
		(with native 64-
					Sun Java Platform Standard Edition JDK 1.5 or 1.6			sparc64Sol2.10jdk
		bit support)
Table 1.10 VxWorks Target Platforms1
	Operating System				CPU	Compiler	RTI Architecture
			PPC 603			gcc 2.96	ppc603Vx5.5gcc
	VxWorks 5.5		PPC 604			gcc 2.96	ppc604Vx5.5gcc
			PPC 750			gcc 2.96	ppc603Vx5.5gcc
			PPC 7400			gcc 2.96	ppc603Vx5.5gcc
							For kernel modules:
	VxWorks 6.3, 6.4		Any Wind River PPC32 CPU with			gcc 3.4.4	ppc604Vx6.3gcc3.4.4
							For Real Time Processes:
			floating point hardware
							ppc604Vx6.3gcc3.4.4_rtp
							For kernel modules:
	VxWorks 6.5		Any Wind River PPC32 CPU with			gcc 3.4.4	ppc604Vx6.5gcc3.4.4
							For Real Time Processes:
			floating point hardware
							ppc604Vx6.5gcc3.4.4_rtp
							For Kernel Modules:
			Pentium			gcc 4.1.2	pentiumVx6.6gcc4.1.2
							For Real Time Processes:
							pentiumVx6.6gcc4.1.2_rtp
							For Kernel Modules:
	VxWorks 6.6		Any Wind River PPC32 CPU with			gcc 4.1.2	ppc604Vx6.6gcc4.1.2
							For Real Time Processes:
			floating point hardware
							ppc604Vx6.6gcc4.1.2_rtp
							For Kernel Modules:
			PPC 4052			gcc 4.1.2	ppc405Vx6.6gcc4.1.2
							For Real Time Processes:
							ppc405Vx6.6gcc4.1.2_rtp

7

				System Requirements
Table 1.10 VxWorks Target Platforms1
	Operating System	CPU	Compiler	RTI Architecture
				For Kernel Modules:
		Pentium	gcc 4.1.2	pentiumVx6.7gcc4.1.2
				For Real Time Processes:
				pentiumVx6.7gcc4.1.2_rtp
				For Kernel Modules:
				ppc604Vx6.7gcc4.1.2
				For Real Time Processes
	VxWorks 6.7	Any Wind River PPC32 CPU with	gcc 4.1.2	on non-SMP systems:
		floating point hardware		ppc604Vx6.7gcc4.1.2_rtp
				For Real Time Processes
				on SMP systems:
				ppc604Vx6.7gcc4.1.2_smp
				For Kernel Modules:
		PPC 4052	gcc 4.1.2	ppc405Vx6.7gcc4.1.2
				For Real Time Processes:
				ppc405Vx6.7gcc4.1.2_rtp
				For Kernel Modules:
		Pentium	gcc 4.1.2	pentiumVx6.8gcc4.1.2
				For Real Time Processes:
				pentiumVx6.8gcc4.1.2_rtp
	VxWorks 6.8
				For Kernel Modules:
		Any Wind River PPC32 CPU with		ppc604Vx6.8gcc4.1.2
			gcc 4.1.2	For Real Time Processes
		floating point hardware		on a non-SMP system:
				ppc604Vx6.8gcc4.1.2_rtp
				For Kernel Modules:
		Pentium32-bit	gcc 4.3.3	pentiumVx6.9gcc4.3.3
				For Real Time Processes:
	VxWorks 6.9			pentiumVx6.9gcc4.3.3_rtp
				For Kernel Modules:
		Any Wind River PPC32 CPU with	gcc 4.3.3	ppc604Vx6.9gcc4.3.3
				For Real Time Processes:
		floating point hardware
				ppc604Vx6.9gcc4.3.3_rtp
	VxWorks 653 2.3	sbc8641d	gcc 3.32	sbc8641Vx653-2.3gcc3.3.2
		SIMPC	gcc 3.32	simpcVx653-2.3gcc3.3.2
	VxWorks MILS 2.1.1	ppc85xx	gcc 3.3.2	ppc85xxVxT2.2.3gcc3.3.2
	with vThreads 2.2.3

1.For use with Windows and/or Solaris Hosts as supported by Wind River Systems.

2.For ppc405, the architecture string is the same for VxWorks 6.6 and 6.7.

Table 1.11 Windows Platforms

	Operating System	CPU	Compiler or	1 2	RTI Architecture
			Software Development Kit
			Visual Studio 2010		i86Win32VS2010
	Windows 7 (32-bit Edition)	x86	Visual Studio 2010 (C++/CLI, C# 8.0 or 9.0)		i86Win32dotnet4.0
			Sun Java Platform Standard Edition JDK 1.6		i86Win32jdk

8

				System Requirements
Table 1.11 Windows Platforms
	Operating System	CPU	Compiler or		RTI Architecture
			Software Development Kit 1 2
			Visual Studio 2010		x64Win64VS2010
	Windows 7 (64-bit Edition)	x64	Visual Studio 2010 (C++/CLI, C# 8.0 or 9.0)		x64Win64dotnet4.0
			Sun Java Platform Standard Edition JDK 1.6		x64Win64jdk
			Visual Studio 2005 SP 1		i86Win32VS2005
			Visual Studio 2005 SP 1 (C++/CLI, C# 8.0 or 9.0)		i86Win32dotnet2.0
	Windows 2003 (32-bit Edition)	x86
			Visual Studio 2008 SP 1		i86Win32VS2008
			Visual Studio 2008 SP 1 (C++/CLI, C# 8.0 or 9.0)		i86Win32dotnet2.0
			Sun Java Platform Standard Edition JDK 1.6		i86Win32jdk
			Visual Studio 2005 SP 1		x64Win64VS2005
	Windows 2003 (64-bit Edition)	x64	Visual Studio 2005 SP 1 (C++/CLI, C# 8.0 or 9.0)		x64Win64dotnet2.0
			Visual Studio 2008 SP 1		x64Win64VS2008
			Sun Java Platform Standard Edition JDK 1.6		x64Win64jdk
			Visual Studio 2005 SP 1 (C++/CLI, C# 8.0 or 9.0)		x64Win64dotnet2.0
	Windows Server 2008 R2	x64	Visual Studio 2010		x64Win64VS2010
	(64-bit Edition)		Visual Studio 2010 (C++/CLI, C# 8.0 or 9.0)		x64Win64dotnet4.0
			Sun Java Platform Standard Edition JDK 1.6		x64Win64jdk
			Visual Studio 2005 SP 1		i86Win32VS2005
			Visual Studio 2005 SP 1 (C++/CLI, C# 8.0 or 9.0)		i86Win32dotnet2.0
	Windows Vista (32-bit Edition)	x86
			Visual Studio 2008 SP 1		i86Win32VS2008
			Visual Studio 2008 SP 1 (C++/CLI, C# 8.0 or 9.0)		i86Win32dotnet2.0
			Sun Java Platform Standard Edition JDK 1.6		i86Win32jdk
			Visual Studio 2005 SP 1		x64Win64VS2005
			Visual Studio 2005 SP 1 (C++/CLI, C# 8.0 or 9.0)		x64Win64dotnet2.0
	Windows Vista (64-bit Edition)	x64
			Visual Studio 2008 SP1		x64Win64VS2008
			Visual Studio 2008 SP 1 (C++/CLI, C# 8.0 or 9.0)		x64Win32dotnet2.0
			Sun Java Platform Standard Edition JDK 1.6		x64Win64jdk
			Visual Studio 2005 SP 1		i86Win32VS2005
	Windows XP Professional3		Visual Studio 2005 SP 1 (C++/CLI, C# 8.0 or 9.0)		i86Win32dotnet2.0
		x86
			Visual Studio 2008 SP 1		i86Win32VS2008
	(32-bit Edition) Service Pack 2
			Visual Studio 2008 SP 1 (C++/CLI, C# 8.0 or 9.0)		i86Win32dotnet2.0
			Sun Java Platform Standard Edition JDK 1.6		i86Win32jdk
			Visual Studio 2005 SP 1		x64Win64VS2005
	Windows XP Professional		Visual Studio 2005 SP 1 (C++/CLI, C# 8.0 or 9.0)		x64Win64dotnet2.0
		x64
			Visual Studio 2008 SP 1		x64Win64VS2008
	(64-bit Edition) Service Pack 2
			Visual Studio 2008 SP 1 (C++/CLI, C# 8.0 or 9.0)		x64Win32dotnet2.0
			Sun Java Platform Standard Edition JDK 1.6		x64Win64jdk

1.On Windows XP: If you are using JDK 5.0 and want to use Intel’s HyperThreading technology, use JDK 5.0 Update 6 (build 1.5.0_06), which includes fixes to JNI and HyperThreading. (If you must use Update 5 (build 1.5.0_05), you should disable HyperThreading.)

9

Compatibility

2.The RTI .NET assemblies are supported for both the C++/CLI and C# languages. The type support code generated by rtiddsgen is in C++/CLI; compiling the generated type support code requires Microsoft Visual C++. Calling the assem- bly from C# requires Microsoft Visual C#.

3.Windows XP does not support IP_TOS unless registry changes are made. See http://support.microsoft.com/kb/248611, http://www.microsoft.com/technet/technetmag/issues/2007/02/CableGuy/default.aspx.

2 Compatibility

RTI strives to provide a seamless upgrade path when the product is updated. When upgrading to a new version of Connext, there are five components to consider:

❏Wire Protocol Compatibility (Section 2.1)

❏Code Compatibility (Section 2.2)

❏Extensible Types Compatibility (Section 2.3)

❏ODBC Database Compatibility (Section 2.4)

❏Transport Compatibility (Section 2.5)

2.1Wire Protocol Compatibility

2.1.1General Information on RTPS (All Releases)

Connext communicates over the wire using the formal Real-time Publish-Subscribe (RTPS) pro- tocol. RTPS has been developed from the ground up with performance, interoperability and extensibility in mind. The RTPS protocol is an international standard managed by the OMG. The RTPS protocol has built-in extensibility mechanisms that enable new revisions to introduce new message types, extend the existing messages, or extend the Quality of Service settings in the product—without breaking interoperability.

RTPS 1.0 was introduced in 2001. The current version is 2.1. RTI plans to maintain interoperabil- ity between middleware versions based on RTPS 2.x.

2.1.2Release-Specific Information for Connext 5.0

2.1.2.1Large Data with Endpoint Discovery

An endpoint (DataWriter or DataReader) created with Connext 5.0 will not be discovered by an application that uses a previous Connext release if any of this conditions are met:

❏The endpoint’s TypeObject is sent on the wire and its size is greater than 65535 bytes. For additional information on TypeObjects, see the new Core Libraries and Utilities Getting Started Guide Addendum for Extensible Types

(RTI_CoreLibrariesAndUtilities_GettingStarted_ExtensibleTypesAddendum.pdf).

❏The endpoint’s UserDataQosPolicy value is greater than 65535 bytes.

TypeObjects and UserDataQosPolicy values with a serialized size greater than 65535 bytes require extended parameterized encapsulation when they are sent as part of the endpoint dis- covery information. This parameterized encapsulation is not understood by previous Connext releases.

10

Compatibility

2.1.3Release-Specific Information for Connext 4.5 and 5.0

Connext 4.5 and 5.0 are compatible with RTI Data Distribution Service 4.2 - 4.5, except as noted below.

2.1.3.1RTPS Versions

Connext 4.5 and 5.0 support RTPS 2.1. Earlier releases (RTI Data Distribution Service 4.2c and lower) supported RTPS 1. Because the two RTPS versions are incompatible with each other, applications built with Connext 4.5 and 5.0 (and RTI Data Distribution Service 4.2e and higher), will not interoperate with applications built using RTI Data Distribution Service 4.2c or lower.

2.1.3.2double, long long, unsigned long long or long double Wire Compatibility

If your Connext application’s data type uses a ‘double,’ ‘long long,’ ‘unsigned long long,’ or ‘long double,’ it will not interoperate with applications built with RTI Data Distribution Service 4.2e or lower, unless you use the -use42eAlignment flag when generating code with rtiddsgen.

2.1.3.3Sending ‘Large Data’ between RTI Data Distribution Service4.4d and Older Releases

The ‘large data’ format in RTI Data Distribution Service 4.2e, 4.3, 4.4b and 4.4c is not compliant with RTPS 2.1. (‘Large data’ refers to data that cannot be sent as a single packet by the transport.)

This issue is resolved in Connext and in RTI Data Distribution Service 4.4d-4.5e. As a result, by default, large data in Connext and in RTI Data Distribution Service 4.4d-4.5e is not compatible with older versions of RTI Data Distribution Service. You can achieve backward compatibility by setting the following properties to 1.

dds.data_writer.protocol.use_43_large_data_format dds.data_reader.protocol.use_43_large_data_format

The properties can be set per DataWriter/DataReader or per DomainParticipant.

For example:

<participant_qos> <property>

<value>

<element>

<name> dds.data_writer.protocol.use_43_large_data_format

</name>

<value>1</value>

</element>

<element>

<name> dds.data_reader.protocol.use_43_large_data_format

</name>

<value>1</value>

</element>

</value> </participant_qos>

2.2Code Compatibility

2.2.1General Information (All Releases)

Connext uses an API that is an extension of the OMG Data Distribution Service (DDS) standard API. RTI strives to maintain API compatibility between versions, but will conform to changes in the OMG DDS standard.

11

Compatibility

Connext primarily consists of a library and a set of header files. In most cases, upgrading simply requires you to recompile your source using the new header files and link the new libraries. In some cases, minor modifications to your application code might be required; any such changes are noted in this document.

RTI allows you to define the data types that will be used to send and receive messages. To create code for a data type, Connext includes a tool called rtiddsgen. For input, rtiddsgen takes a data- type description (in IDL, XML, XSD, or WSDL format); rtiddsgen generates header files (or a class in Java) that can be used to send and receive data of the defined type. It also generates code that takes care of low-level details such as transforming the data into a machine-independent representation suitable for communication.

While this is not the common case, some upgrades require you to regenerate the code produced by rtiddsgen. The regeneration process is very simple; you only need to run the new version of rtiddsgen using the original input IDL file. This process will regenerate the header and source files, which can then be compiled along with the rest of your application.

2.2.2Release-Specific Information for Connext 5.0

This section points out important differences in Connext 5.0 that may require changes on your part when upgrading to this release.

2.2.2.1Required Change for Building with C++ Libraries for QNX Platforms—New in 5.0.0

For QNX architectures, starting in release 5.0.0: The C++ libraries are now built without the -fno-rtti flag and with the -fexceptions flag. To build QNX architectures starting with release 5.0.0, you must build your C++ applications without -fno-exceptions in order to link with the RTI libraries. In summary:

❏Do not use -fno-exceptions when building a C++ application or the build will fail. It is not necessary to use -fexceptions, but doing so will not cause a problem.

❏It is no longer necessary to use -fno-rtti, but doing so will not cause a problem.

2.2.2.2Changes to the Custom Content Filters API

In Connext 5.0, the ContentFilter’s ‘evaluate’ function now receives a new ‘struct DDS_FilterSampleInfo *’ parameter that allows it to filter on meta-data.

The ‘evaluate’ function of previous custom filter implementations must be updated to add this new parameter.

2.2.2.3Changes in Generated Type Support Code

The rtiddsgen-generated type-support code for user-defined data type changed in 5.0 to facilitate some new features. If you have code that was generated with rtiddsgen 4.5 or lower, you must regenerate that code using the version of rtiddsgen provided with this release.

2.2.3Release-Specific Information for Connext 4.5 and 5.0

2.2.3.1Type Support and Generated Code Compatibility

❏long long Native Data Type Support

In Connext (and RTI Data Distribution Service 4.5c,d,e), we assume all platforms natively support the ‘long long’ data type. This was not the case in older versions of RTI Data Dis- tribution Service. There is no longer a need to define RTI_CDR_SIZEOF_LONG_LONG to be 8 on some platforms in order to map the DDS ‘long long’ data type to a native ‘long long’ type.

12

Compatibility

❏double, long long and unsigned long long Code Generation

If your Connext (or RTI Data Distribution Service 4.3-4.5e) application’s data type uses a ‘double,’ ‘long long,’ ‘unsigned long long,’ or ‘long double,’ it will not be backwards compatible with applications built with RTI Data Distribution Service 4.2e or lower, unless you use the -use42eAlignment flag when generating code with rtiddsgen.

❏Changes in Generated Type Support Code

The rtiddsgen-generated type-support code for user-defined data type changed in 4.5 to facilitate some new features. If you have code that was generated using rtiddsgen 4.4 or lower, you must regenerate that code using the version of rtiddsgen provided with this release.

❏Cross-Language Instance Lookup when Using Keyed Data Types

This issue only impacts systems using RTI Data Distribution Service 4.3.

In RTI Data Distribution Service 4.3, keys were serialized with the incorrect byte order when using the Java and .NET1 APIs for the user-defined data type, resulting in incorrect behavior in the lookup_instance() and get_key() methods when using keyed data-types to communicate between applications in these languages and other programming lan- guages. This issue was resolved in Java starting in RTI Data Distribution Service 4.3e rev. 01 and starting in .NET in RTI Data Distribution Service 4.4b.

As a result of this change, systems using keyed data that incorporate Java or .NET appli- cations using both RTI Data Distribution Service 4.3 and this Connext release could experi- ence problems in the lookup_instance() and get_key() methods. If you are affected by this limitation, please contact RTI Support.

❏Data Type with Variable-Size Keys

If your data type contains more than one key field and at least one of the key fields except the last one is of variable size (for example, if you use a string followed by a long as the key):

•RTI Data Distribution Service 4.3e, 4.4b or 4.4c DataWriters may not be compatible with RTI Data Distribution Service 4.4d or higher DataReaders.

•RTI Data Distribution Service 4.3e, 4.4b or 4.4c DataReaders may not be compatible with RTI Data Distribution Service 4.4d or higher DataWriters.

Specifically, all samples will be received in those cases, but you may experience the fol- lowing problems:

•Samples with the same key may be identified as different instances. (For the case in which the DataWriter uses RTI Data Distribution Service 4.4d-4.5e or Connext, this can only occur if the DataWriter’s disable_inline_keyhash field (in the DataWriter- ProtocolQosPolicy) is true (this is not the default case).

•Calling lookup_instance() on the DataReader may return HANDLE_NIL even if the instance exists.

Please note that you probably would have had the same problem with this kind of data type already, even if both your DataWriter and DataReader were built with RTI Data Dis- tribution Service 4.3e, 4.4b or 4.4c.

1. RTI Connext .NET language binding is currently supported for C# and C++/CLI.

13

Compatibility

If you are using a C/C++ or Java IDL type that belongs to this data type category in your RTI Data Distribution Service 4.3e, 4.4b or 4.4c application, you can resolve the backwards compatibility problem by regenerating the code with version of rtiddsgen distributed with RTI Data Distribution Service 4.4d. You can also upgrade your whole system to this release.

2.2.3.2Other API and Behavior Changes

❏Code Compatibility Issue in C++ Applications using Dynamic Data

If you are upgrading from a release prior to 4.5f and use Dynamic Data in a C++ applica- tion, you may need to make a minor code change to avoid a compilation error.

The error would be similar to this:

MyFile.cpp:1060: warning: extended initializer lists only available with -std=c++0x or -std=gnu++0x

MyFile.cpp:1060: warning: extended initializer lists only available with -std=c++0x or -std=gnu++0x

MyFile.cpp:1060: error: could not convert ‘{0l, 65536l, 1024l}’ to ‘DDS_DynamicDataProperty_t’

MyFile.cpp:1060: error: could not convert ‘{0u, 4294967295u, 4294967295u, 0u}’ to ‘DDS_DynamicDataTypeSerializationProperty_t

The code change involves using a constructor instead of a static initializer. Therefore if you have code like this:

DDS_DynamicDataTypeProperty_t properties = DDS_DynamicDataTypeProperty_t_INITIALIZER;

...

typeSupport = new DDSDynamicDataTypeSupport(typeCode, properties);

Replace the above with this:

DDS_DynamicDataTypeProperty_t properties;

...

typeSupport = new DDSDynamicDataTypeSupport(typeCode, properties);

❏New on_instance_replaced() method on DataWriterListener

Starting with RTI Data Distribution Service 4.5c (and thereby included in Connext), there is a new DataWriterListener method, on_instance_replaced(), which supports the new instance replacement feature. This method provides notification that the maximum instances have been used and need to be replaced. If you are using a DataWriterListener from an older release, you may need to add this new method to your listener.

❏Counts in Cache Status and Protocol Status changed from Long to Long Long

Starting with RTI Data Distribution Service 4.5c (and thereby included in Connext), all the ‘count’ data types in DataReaderCacheStatus, DataReaderProtocolStatus, DataWriter-

CacheStatus and DataWriterProtocolStatus changed from ‘long’ to ‘long long’ in the C, C++ and .NET1 APIs in order to report the correct value for Connext applications that run for very long periods of time. If you have an application written with a previous release of RTI Data Distribution Service that is accessing those fields, data-type changes may be necessary.

1.RTI Connext .NET language binding is currently supported for C# and C++/CLI.

14

Compatibility

❏Changes in RtpsReliableWriterProtocol_t

Starting with RTI Data Distribution Service 4.4c (and thereby included in Connext), two fields in DDS_RtpsReliableWriterProtocol_t have been renamed:

•Old name: disable_positive_acks_decrease_sample_keep_duration_scaler New name:disable_positive_acks_decrease_sample_keep_duration_factor

•Old name: disable_positive_acks_increase_sample_keep_duration_scaler New name: disable_positive_acks_increase_sample_keep_duration_factor

In releases prior to 4.4c, the NACK-only feature was not supported on platforms without floating-point support. Older versions of RTI Data Distribution Service will not run on these platforms because floats and doubles are used in the implementation of the NACK- only feature. In releases 4.4c and above, the NACK-only feature uses fixed-point arithme- tic and the new DDS_Long "factor" fields noted above, which replace the DDS_Double "scaler" fields.

❏Tolerance for Destination-Ordering by Source-Timestamp

Starting with RTI Data Distribution Service 4.4b (and thereby included in Connext), by default, the middleware is less restrictive (compared to older releases) on the writer side with regards to timestamps between consecutive samples: if the timestamp of the current sample is less than the timestamp of the previous sample by a small tolerance amount, write() will succeed.

If you are upgrading from RTI Data Distribution Service 4.4a or lower, and the application you are upgrading relied on the middleware to reject timestamps that ‘went backwards’ on the writer side (that is, when a sample’s timestamp was earlier than the previous sam- ple’s), there are two ways to keep the previous, more restrictive behavior:

•If your DestinationOrderQosPolicy’s kind is BY_SOURCE_TIMESTAMP: set the new field in the DestinationOrderQosPolicy, source_timestamp_tolerance, to 0.

•If your DestinationOrderQosPolicy's kind is BY_RECEPTION_TIMESTAMP on the writer side, consider changing it to BY_SOURCE_TIMESTAMP instead and setting source_timestamp_tolerance to 0. However, this may not be desirable if you had a particular reason for using BY_RECEPTION_TIMESTAMP (perhaps because you did not want to match readers with BY_SOURCE_TIMESTAMP). If you need to keep the BY_RECEPTION_TIMESTAMP setting, there is no QoS set- ting that will give you the exact same behavior on the writer side as the previous release.

Starting with RTI Data Distribution Service 4.4b (and thereby included in Connext), by default, the middleware is more restrictive (compared to older releases) on the reader side with regards to source and reception timestamps of a sample if DestinationOrder- QosPolicy kind is set to BY_SOURCE_TIMESTAMP: if the reception timestamp of the sample is less than the source timestamp by more than the tolerance amount, the sample will be rejected.

If you are upgrading from RTI Data Distribution Service 4.4a or lower, your reader is using BY_SOURCE_TIMESTAMP, and you need the previous less restrictive behavior, set source_timestamp_tolerance to infinite on the reader side.

❏New Location and Name for Default XML QoS Profiles File (formerly NDDS_QOS_PROFILES.xml)

Starting with RTI Data Distribution Service 4.4d (and thereby included in Connext) the default XML QoS Profiles file has been renamed and is installed in a new directory:

15

Compatibility

•Old location/name: $NDDSHOME/resource/xml/NDDS_QOS_PROFILES.xml

•New location/name: $NDDSHOME/resource/qos_profiles_<version>/xml/ NDDS_QOS_PROFILES.example.xml (where <version> can be 4.4d, for example)

If you want to use this QoS profile, you need to set up your NDDSHOME environment variable at run time and rename the file NDDS_QOS_PROFILES.example.xml to NDDS_QOS_PROFILES.xml (i.e., by default, even if your NDDSHOME environment variable is set, this QoS profile is not used.) See Section 15.2 in the RTI Core Libraries and Utilities User’s Manual for details.

❏Changes in the default value for the max_objects_per_thread field

Starting with RTI Data Distribution Service 4.4d (and thereby included in Connext), the default value for the max_objects_per_thread field in the SystemResourceLimitsQosPol- icy has been changed from 512 to 1024.

❏Type Change in Constructor for SampleInfoSeq—.NET1 Only

Starting with RTI Data Distribution Service 4.5c (and thereby included in Connext), the constructor for SampleInfoSeq has been changed from SampleInfoSeq(UInt32 maxSam- ples) to SampleInfoSeq(Int32 maxSamples). This was to make it consistent with other sequences.

❏Default Send Window Sizes Changed to Infinite

•Starting with RTI Data Distribution Service 4.5d (and thereby included in Connext), the send window size of a DataWriter is set to infinite by default. This is done by changing the default values of two fields in DDS_RtpsReliableWriterProtocol_t (min_send_window_size, max_send_window_size) to be DDS_LENGTH_UNLIMITED.

•In RTI Data Distribution Service 4.4d, the send window feature was introduced and was enabled by default in 4.5c (with min_send_window_size = 32, max_send_window_size = 256). For DataWriters with a HistoryQosPolicy kind of KEEP_LAST, enabling the send window could cause writes to block, and possibly fail due to blocking timeout. This blocking behavior changed the expected behav- ior of applications using default QoS. To preserve that preestablished non-blocking default behavior, the send window size has been changed to be infinite by default starting in release 4.5d.

•Users wanting the performance benefits of a finite send window will now have to configure the send window explicitly.

2.3Extensible Types Compatibility

Connext 5.0 includes partial support for the "Extensible and Dynamic Topic Types for DDS" (DDS-XTypes) specification2 from the Object Management Group (OMG). This support allows systems to define data types in a more flexible way, and to evolve data types over time without giving up portability, interoperability, or the expressiveness of the DDS type system.

For information related to compatibility issues associated with the Extensible Types support, see the new Core Libraries and Utilities Getting Started Guide Addendum for Extensible Types

(RTI_CoreLibrariesAndUtilities_GettingStarted_ExtensibleTypesAddendum.pdf).

1.RTI Connext .NET language binding is currently supported for C# and C++/CLI.

2.http://www.omg.org/spec/DDS-XTypes/

16

Compatibility

2.4ODBC Database Compatibility

To use the Durable Writer History and Durable Reader State features, you must install a rela- tional database such as MySQL.

In principle, you can use any database that provides an ODBC driver, since ODBC is a standard. How- ever, not all ODBC databases support the same feature set. Therefore, there is no guarantee that the persistent durability features will work with an arbitrary ODBC driver.

We have tested the following driver:

❏MySQL ODBC 5.1.44

Note: Starting with 4.5e, support for the TimesTen database has been removed.

To use MySQL, you will also need the MySQL ODBC 5.1.6 (or higher) driver. For non-Windows platforms, UnixODBC 2.2.12 (or higher) is also required.

The Durable Writer History and Durable Reader State features have been tested with the follow- ing architectures:

❏AIX: p5AIX5.3xlc9.0, 64p5AIX5.3xlc9.0

❏Linux: i86Linux2.6gcc3.4.3, x64Linux2.6gcc3.4.5; i86Linux2.6gcc4.1.1, x64Linux2.6gcc4.1.1; i86Linux2.6gcc4.4.3, x64Linux2.6gcc4.4.3

❏Solaris: sparcSol2.10gcc3.4.2, sparc64Sol2.10gcc3.4.2

❏Windows: i86Win32VS2005, i86Win32VS2008, i86Win32VS2010, x64Win64VS2010

For more information on database setup, please see the Addendum for Database Setup

(RTI_CoreLibrariesAndUtilities_GettingStarted_DatabaseAddendum.pdf).

2.5Transport Compatibility

The shared memory transport in Connext does not interoperate with the shared memory trans- port in previous releases of RTI Data Distribution Service.

If two applications, one using Connext and one using RTI Data Distribution Service, run on the same node and they have the shared memory transport enabled, they will fail with the follow- ing error:

[D0004|CREATE Participant|D0004|ENABLE] NDDS_Transport_Shmem_is_segment_compatible:incompatible shared memory protocol detected.

Current version 1.0 not compatible with 2.0.

If you have an interoperability requirement and you cannot switch to UDPv4, please contact support@rti.com.

17

What’s Fixed in Connext 5.0.0

3 What’s Fixed in Connext 5.0.0

This section describes bugs fixed since the release of Connext 4.5f.

3.1Fixes Related to Batching

3.1.1Unkeyed DataReader using KEEP_LAST History Sometimes Stopped Receiving Data

This is a rare situation that only occurs when the DataReader receives samples from a DataW- riter using batching and when the DataReader have loans on samples that are replaced after applying the history depth.

[RTI Issue ID CORE-5097, Bug # 14324]

3.2Fixes Related to Content Filtering

3.2.1get_matched_subscription_data() Returned Empty Structure for content_filter_property

The DataWriter’s get_matched_subscription_data() operation populates a DDS_SubscriptionBuiltinTopicData structure. However the content_filter_property member of that structure contained all NULLs, even if there was a DataReader on a matched ContentFil- teredTopic. This problem has been resolved.

[RTI Issue ID CORE-5079]

3.2.2Incorrect Filtering Applied to DataReaders with Non-Volatile Durability if DataWriter used ON_DEMAND Refiltering

Content-filtering for DataReaders with non-volatile Durability may not have worked as expected in some cases. The DataReader may have either received samples that should have been filtered out, or may have not received samples it should have gotten. This problem only existed if the DataWriter's HistoryQosPolicy refilter field was set to ON_DEMAND.

[RTI Issue ID CORE-4131]

3.2.3Parsing Error if Multi-Channel DataWriter had Empty Filter Expression

If the filter expression for a channel of a multi-channel DataWriter was set to the empty string (for example, by using <filter_expression></filter_expression> in the XML configuration file), you may have seen a parser error. This occurred if a DataReader was discovered that used a Con- tentFilteredTopic based on the same topic used by the multi-channel DataWriter. This problem had been resolved; now an empty filter expression (empty string) is allowed for multi-channel

DataWriters.

[RTI Issue ID CORE-5431]

3.2.4SqlFilter Compile Error with Enumeration Values—Java API Only

In previous releases, after a DomainParticipant discovered a DataReader with a ContentFiltered- Topic, the compilation of the DataReader’s filter expression may have failed with the following error if the filter expression contained enumeration values:

SqlFilter.compile:Combination of different enum types not allowed. ContentFilteredTopicImpl_forward_compile:!compile expression

This problem had been resolved.

[RTI Issue ID CORE-4200]

18

What’s Fixed in Connext 5.0.0

3.3Fixes Related to Reliability Protocol

3.3.1DataReader Processed Duplicate Heartbeat Messages

A DataReader may have processed duplicate heartbeat messages (caused by the presence of redundant communication paths) multiple times. This problem has been resolved.

[RTI Issue ID CORE-5136]

3.3.2DataWriter Protocol Statistics did not Include First HeartBeat Sent to VOLATILE DataReader

Statistics retrieved from the following DataWriter operations may not have accounted for the first heartbeat (HB) message sent to a DataReader configured with VOLATILE Durability.

❏get_datawriter_protocol_status()

❏get_matched_subscription_datawriter_protocol_status()

❏get_matched_subscription_datawriter_protocol_status_by_locator()

This problem has been resolved.

[RTI Issue ID CORE-5149]

3.3.3Reliable DataWriter Sending Large Data may not have Inactivated Non-Progressing DataReader

When DDS_RtpsReliableWriterProtocol_t.inactivate_nonprogressing_readers is set to TRUE, a reliable DataWriter should treat any DataReader that is not showing progress in receiving and acknowledging samples (after max_heartbeat_retries) as inactive. However, for reliable DataW- riters sending large samples that are fragmented by the middleware, a problem existed where a DataWriter did not inactivate a DataReader that was continuously requesting for the same data fragment to be resent. This problem has been resolved.

[RTI Issue ID CORE-5163]

3.3.4Unexpected Timeout Error from Write Operation

This problem only occurred in version 4.5e Rev. 07 when a DataWriter was configured for strict reliability (that is, Reliability QoS kind = Reliable and History QoS kind = KEEP_ALL) and its ResourceLimits QoS max_samples was set to a finite value (which is not the default case).

Even if the existing reliable DataReaders had acknowledged all the samples in the DataWriter’s queue, the write operation may have returned DDS_RETCODE_TIMEOUT when the queue filled up. The write operation blocked until the next periodic HeartBeat message was sent. This situation only occurred when a DataReader was matched.

[RTI Issue ID CORE-5214]

3.3.5False Reporting of Samples Lost if Late-Joining Readers did not Include Expired Samples

DataWriters whose LifespanQosPolicy was set to a finite value did not deliver samples with expired lifespan to DataReaders. However, in the case of late-joining DataReaders, the initial HeartBeat messages from the DataWriter to the DataReader did include the expired samples. Sub- sequently, the DataReader would request these samples, but the DataWriter would not send them. This caused the DataReader to report samples lost to the application.

This behavior has been changed so that the HeartBeat message now includes samples with expired lifespans, thus removing the spurious samples lost on the reader side.

[RTI Issue ID CORE-5074; Bug # 14374]

3.3.6Lowered Verbosity for "ACK Ignored" Messages

If a DataWriter dropped an ACKNACK message, Connext would log a warning ("ACK ignored

..."). However, an ACK might also be ignored because of a valid scenario (described below);

19

What’s Fixed in Connext 5.0.0

therefore the verbosity for the “ACK ignored” message has been changed from WARNING to REMOTE.

For example, this is a valid scenario in which an ACK may be ignored: A DataWriter has just inactivated a remote DataReader and the ACKNACK is stale (sent before the DataWriter inacti- vated the DataReader). This situation is a false-alarm.

In this release, the verbosity of the "ACK ignored" messages has been changed to REMOTE instead of WARNING.

[RTI Issue ID CORE-5170]

3.4Fixes Related to Transports

3.4.1Possible Errors when Using Shared Memory on PPC SMP Board with VxWorks

When using the shared memory transport on a PPC SMP board running VxWorks, you may have seen the following error messages:

PRESCstReaderCollator_storeInlineQos:!serialized sample to keyhash PRESCstReaderCollator_newAnonData:!add store inline QoS

This problem has been resolved.

[RTI Issue ID CORE-5122]

3.4.2Shared Memory Send Failures not Reported

In previous Connext releases, the shared memory transport did not print any messages when the execution of the send operation failed because the shared memory transport queue was full. This release prints a message indicating this situation with a NDDS_CONFIG_LOG_VERBOSITY_STATUS_LOCAL verbosity level.

[RTI Issue ID CORE-3457]

3.5Fixes Related to Dynamic Data

3.5.1Corrected Implementation of DynamicData's get/set_wstring API

In the previous release, Connext did not convert the wchar_t representation (2 bytes) to the DDS_Wchar representation (4 bytes). This caused an incompatible representation. For example, when sending a wstring containing "Hello World" the receiving application may have received the wrong content (such as just the “H”.) This problem has been resolved.

[RTI Issue ID CORE-4204, Bug # 14316]

3.5.2Issues when Using Untyped Methods on Dynamic DataWriter—Java API Only

Some applications may have generic, type-independent modules. Their code uses the com.rti.dds.publication.DataWriter interface and its untyped methods (write_untyped(), dispose_untyped(), register_instance_untyped() and unregister_instance_untyped()).

When the actual object was a DynamicDataWriter, using those methods resulted in undefined behavior. This problem has been resolved; using the untyped methods is now equivalent to using the type-specific ones. For example, the two write operations below are equivalent:

DynamicDataWriter dynamicDataWriter = publisher.create_datawriter(...);

DataWriter writer = dynamicDataWriter;

DynamicData sample = typeSupport.create_data();

dynamicDataWriter.write(sample, InstanceHandle_t.HANDLE_NIL);

writer.write_untyped(sample, InstanceHandle_t.HANDLE_NIL);

[RTI Issue ID CORE-5215]

20

What’s Fixed in Connext 5.0.0

3.5.3Creating Two ContentFilteredTopics Based on DynamicData Topic on Same Participant Failed— Java API Only

After creating a ContentFilteredTopic based on a DynamicData topic, an attempt to create another ContentFilteredTopic, based on the same or a different DynamicData topic, on the same Participant would fail. This problem has been resolved; now any number of ContentFilteredTop- ics can be created. This problem only occurred when using the Java API.

[RTI Issue ID CORE-4227, Bug # 14354]

3.5.4Possible Deserialization Error When Using Dynamic Data and Extensible Types

There was a possible deserialization error when using Dynamic Data and Extensible Types. If a DataReader expected an Extensible type, but received a Base type instead, you may have seen this error:

DDS_DynamicData_initialize_from_bufferI:ERROR: Failed to get sample init error

This issue has been resolved.

[RTI Issue ID CORE-5340]

3.6Fixes Related to XML Parser

3.6.1Calls to create_<entity>_with_profile would Hang if DomainParticipant used Monitoring Library

If the DomainParticipant was configured to use RTI Monitoring Library, calls to the following operations would hang:

❏Publisher’s create_datawriter_with_profile()

❏Subscriber’s create_datareader_with_profile()

❏DomainParticipant’s create_topic_with_profile()

This problem has been resolved.

[RTI Issue ID CORE-5152]

3.6.2No Error Reported when QoS Profile Tag Defined Multiple Times in XML QoS Profile

The XML configuration parser failed to report an error if a QoS profile tag was defined multiple times within an XML QoS Profile. For example:

<qos_library name="PropertyInheritanceLib"> <qos_profile name="BaseProfile">

<datareader_qos>

<property>

...

</property>

<property>

...

</property> </datareader_qos>

</qos_profile> </qos_library>

This problem has been resolved. Now this erroneous configuration will be reported as an error.

[RTI Issue ID CORE-5204]

21

What’s Fixed in Connext 5.0.0

3.7Fixed Related to Read Conditions

3.7.1ReadCondition Reported Erroneous Status for Keyed Reader Following NOT_ALIVE Status

For keyed types, if an instance became NOT_ALIVE because it was disposed or due to a NO_WRITERS condition, if and when the instance returned to ALIVE status, ReadConditions for that DataReader misreported available samples when they were not present. Since the sample was not really present, it could not be taken; therefore the condition could not be cleared. This problem has been resolved.

[RTI Issue ID CORE-5178]

3.7.2ReadCondition Created from Disabled Reader Never Triggered

If a ReadCondition was created while its associated DataReader was disabled, the ReadCondition was never triggered (even if the DataReader was subsequently enabled). ReadConditions that were created (or re-created) after the DataReader was enabled were unaffected. This problem has been resolved; now a ReadCondition can be created while a DataReader is disabled and it will function correctly once the DataReader is enabled.

[RTI Issue ID CORE-5324]

3.8Fixes Related to Experimental Features

3.8.1Incomplete Cleanup if create_participant_from_config_exp() Failed to Create Underlying Entities

A call to create_participant_from_config_exp() creates a DomainParticipant and all the underly- ing entities defined in the corresponding configuration. If an error occurs while creating one of these entities (after the DomainParticipant has been created), create_participant_from_config() should delete all the entities that it created before encountering the failure, then return NULL. However, the DomainParticipant and any underlying entities that were created were not deleted before returning. This resulted in an error if finalize() was invoked on the DomainParticipant- Factory. This problem has been resolved.

[RTI Issue ID CORE-5071]

3.9Other Fixes

3.9.1Potential Precondition Errors if Asynchronous Publisher Feature Used by Persistence Service DataWriter or DataWriter Using Durable Writer History

A DataReader receiving fragmented samples from a DataWriter configured to use durable writer history or from a Persistence Service DataWriter configured in PERSISTENT mode may report precondition errors that will cause samples to be dropped.

This problem has been fixed. [RTI Issue ID CORE-5345]

3.9.2Potential Segmentation Fault on QNX Architectures

Previous Connext releases may have issued a segmentation fault on QNX architectures due to the internal usage of random(), which is a non-reentrant function. This problem has been resolved by replacing random() with rand_r().

[RTI Issue ID CORE-5294]

3.9.3DDS Built-in Types did not Include C++ Traits

In release 4.5f, types generated with rtiddsgen for C++ included traits that allowed the type of related DDS entities (such us DataWriter, DataReader, Sequence types, etc.) to be inferred.

22

What’s Fixed in Connext 5.0.0

This information was not available for the DDS built-in types (Octets, KeyedOctets, String, and KeyedString). Therefore the templatized functions that used these traits could not be instanti- ated with one of the built-in types.

This problem has been resolved for Octets, KeyedOctets and KeyedString. The String built-in type is a special case (char* is a primitive type) and this feature is not currently supported.

[RTI Issue ID CORE-5096]

3.9.4Some DDS Infrastructure Types Lacked Copy Constructors—C++ API Only

The C++ API for some infrastructure types lacked copy constructors. This affected QoS policies and the built-in types DDS_KeyedString, DDS_Octets and DDS_KeyedOctets. This problem made it impossible to make copies or pass parameters by value. This problem has been resolved and copy constructors have been added.

[RTI Issue ID CORE-2588; Bug # 12181]

3.9.5DataReaders with Default Character Encoding Other Than ISO-8859-1 may have Received Corrupt Characters when using IDL Types with Strings—Java API Only

DataReaders that used default character encoding other than ISO-8859-1 could have received cor- rupt characters if the IDL type included strings. This did not affect common English characters, but may have been an issue with special characters in other languages, such as German charac- ters ö, ä, and ü. This problem has been resolved.

[RTI Issue ID CORE-3825; Bug # 13793]

3.9.6Calls to wait_for_historical_data() Could Return Prematurely

If wait_for_historical_data() was called while there were multiple remote DataWriters matched with the calling DataReader, it was possible for wait_for_historical_data() to return before all of the historical data had been received. This problem has been resolved.

[RTI Issue ID CORE-5076; Bug # 14361]

3.9.7Participant Creation Failure if Network Interface had IP Address 0.0.0.0

DomainParticipant creation may have failed with the following errors if a network interface had the invalid IP address 0.0.0.0:

[CREATE Participant]COMMENDActiveFacade_new:!precondition [CREATE Participant]PRESParticipant_new:!create facade

[CREATE Participant]DDS_DomainParticipantPresentation_initialize: !create participant core

[CREATE Participant]DDS_DomainParticipant_createI:!create presentation participant [CREATE Participant]DDS_DomainParticipantFactory_create_participant_disabledI: !create participant

DDSDomainParticipant_impl::create_disabledI:!create participant DDSDomainParticipant_impl::createI:!create participant DomainParticipantFactory_impl::create_participant():!create failure creating participant create_participant error

This problem has been resolved.

[RTI Issue ID CORE-5103]

3.9.8Unreachable Address not Included in Error Message

During the discovery process, participants receive other participants’ locator lists. If the locator list contained an unreachable address, the resulting error message did not include the address. For example, you may have seen this message:

RTINetioSender_addDestination: no transport for request

In this release, the error message includes the address that could not be reached.

23

What’s Fixed in Connext 5.0.0

For example, if no transport can be found for a UDPv4 address, the message will resemble:

RTINetioSender_addDestination:no transport for destination request udpv4:// 10.30.1.205:21410

If no transport can be found for a SHMEM address, you will see a message such as:

RTINetioSender_addDestination:no transport for destination request shmem:// 0002:0007:0105:0000:0000:0000:0000:0000:21410

For other transports, the message will be:

<transport class name>://xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:<port>

{RTI Issue ID CORE-5220]

3.9.9VxWorks 6.7 RTP Mode Support for SMP Boards

The Connext libraries for the VxWorks 6.7 RTP mode platform used deprecated VxWorks system calls, which made the libraries incompatible on multi-processor boards. The deprecated calls are no longer used and VxWorks 6.7 RTP libraries can now be used on single- and multi-processor boards.

[RTI Issue ID CORE-5265]

3.9.10Possible Segmentation Fault or Precondition Error if Cumulative String Length of Properties Exceeded Maximum

If the participant_property_string_max_length in the DomainParticipantResourceLimitsQo- sPolicy was greater than the DomainParticipant's properties' cumulative length without the null terminating characters, but less than or equal to the cumulative length with the null terminating characters, you may have seen either a segmentation fault when using the release libraries, or the following errors when using the debug libraries:

[D0000|CREATE Participant|D0000|ENABLE]PRESPropertyQosPolicy_copy:

!precondition

[D0000|CREATE Participant|D0000|ENABLE]PRESParticipant_getProperty:

!copyPropertyPolicy

[D0000|CREATE Participant|D0000|ENABLE]DDS_DomainParticipantPresentation

_get_qos:ERROR: Failed to get QoS

[D0000|CREATE Participant|D0000|ENABLE]DDS_DomainParticipant_enableI:

ERROR: Failed to get participant QoS

[D0000|CREATE Participant]DDS_DomainParticipantFactory_create_participant:

ERROR: Failed to auto-enable entity

For example, this problem would occur if participant_property_string_max_length was 10 and there were two properties: <name="12", value="34"> and <name="567", value="890">. Since the cumulative length with the null terminating characters was 14, which is greater than 10, the cor- rect behavior is for Connext to print these error messages:

[CREATE Participant]DDS_ResourceLimitsQosPolicy_is_consistentI:inconsistent QoS policies: cumulative string length of the properties and DDS_DomainParticipantQos.resource_limits.participant_property_string_ max_length

[CREATE Participant]DDS_DomainParticipantQos_is_consistentI:inconsistent QoS policy: property

[CREATE Participant]DDS_DomainParticipantFactory_set_default_participant_qos: ERROR:Inconsistent QoS

[RTI Issue ID CORE-5288]

3.9.11Reader Memory Growth if Number of Received Instances Exceeded max_total_instances

If a DataReader received more instances than its reader_resource_limits.max_total_instances,

Connext did not completely free the memory associated with the replaced existing instance. This

24

Known Issues

led to memory growth whenever an existing instance was replaced. This problem has been resolved.

[RTI Issue ID CORE-5302]

3.9.12Possible Incorrect Instance Handle Received if disable_inline_keyhash Enabled—.NET APIs only

If a DataWriter set the DataWriterProtocolQosPolicy's disable_inline_keyhash to TRUE, a sub- scribing application with multiple matching DataReaders for that DataWriter may have received an incorrect instance handle. A DataReader may have retrieved the instance handle for a sample that was received by a different DataReader. This could have caused the DataReader to drop a sample or get incorrect meta-data for a sample. This problem, which only affected the C# and C++/CLI APIs, has been resolved.

[RTI Issue ID CORE-5303]

3.9.13Small channel_seq_max_length Resulted in Segmentation Fault

A small value for the DomainParticipantResourceLimitsQosPolicy’s channel_seq_max_length (between 1 and 4, inclusive) may have resulted in a segmentation fault. This problem has been resolved.

[RTI Issue ID CORE-5332]

3.9.14Errors from RTI Spy and Ping Tools when Using VxWorks Kernel Mode

The rtiddsspy and rtiddsping tools could not be used on VxWorks platforms using kernel mode. You may have seen "undefined reference" errors. This problem has been resolved.

[RTI Issue ID CORE-5353]

4 Known Issues

4.1AppAck Messages Cannot be Greater Than Underlying Transport Message Size

A DataReader with acknowledgment_kind (in the ReliabilityQosPolicy) set to DDS_APPLICATION_AUTO_ACKNOWLEDGMENT_MODE or DDS_APPLICATION_EXPLICIT_ACKNOWLEDGMENT_MODE cannot send AppAck mes- sages greater than the underlying transport message size.

If a DataReader tries to send an AppAck message greater than the transport message size, Con- next will print the following error message:

COMMENDFacade_sendAppAck:!add APP_ACK to MIG

COMMENDSrReaderService_sendAppAck:!send APP_ACK

PRESPsService_onReaderAppAckSendEvent:!send acknowledgment

To recover from the above error, the DataReader must acknowledge samples until the size of the AppAck message goes below the transport message size threshold.

Why does an AppAck message increase its size?

An AppAck message contains a list of sequence number intervals where each interval repre- sents a set of consecutive sequence numbers that have been already acknowledged.

As long as samples are acknowledged in order, the AppAck message will always have a single interval. However, when samples are acknowledged out of order, the number of intervals and the size of the AppAck will increase.

25

Known Issues

For additional information, see Section 6.3.12, Application Acknowledgment, in the RTI Core Librar- ies and Utilities User’s Manual.

[RTI Issue ID CORE-5329]

4.2DataReader Cannot Persist AppAck Messages Greater Than 32767 Bytes

A DataReader using durable reader state, whose acknowledgment_kind (in the ReliabilityQo- sPolicy) is set to DDS_APPLICATION_AUTO_ACKNOWLEDGMENT_MODE or DDS_APPLICATION_EXPLICIT_ACKNOWLEDGMENT_MODE, cannot persist an AppAck message greater than 32767 bytes.

To recover from the previous error, the DataReader must acknowledge samples until the size of the AppAck message goes below the transport message size threshold.

For additional information, see Section 12.4, Durable Reader State, in the RTI Core Libraries and Utilities User’s Manual.

[RTI Issue ID CORE-5360]

4.3Request and Reply Topics Must be Created with Types Generated by rtiddsgen—C API Only

When using the C API to create Request and Reply Topics, these topics must use data types that have been generated by rtiddsgen. Other APIs support using built-in types and DynamicData types.

[RTI Issue ID BIGPINE-537]

4.4Writer-Side Filtering May Cause Missed Deadline

If you are using a ContentFilteredTopic and you set the Deadline QosPolicy, the deadline may be missed due to filtering by a DataWriter.

[RTI Issue ID CORE-1634, Bug # 10765]

4.5Writer-side Filtering Functions Can be Invoked Even After Filter Unregistered

If you install a ContentFilter that implements the writer-side filtering APIs, Connext can call those APIs even after the ContentFilter has been unregistered.

[RTI Issue ID CORE-5356]

4.6Disabled Interfaces on Windows Systems

The creation of a DomainParticipant will fail if no interface is enabled and the DiscoveryQosPol- icy.multicast_receive_addresses list (specified either programmatically, or through the NDDS_DISCOVERY_PEERS file or environment variable) contains a multicast address.

However, if NDDS_DISCOVERY_PEERS only contains unicast addresses, the DomainPartici- pant will be successfully created even if all the interfaces are disabled. The creation of a DataReader will fail if its TransportMulticastQosPolicy contains a UDPv4 or UPDv6 multicast address.

4.7Wrong Error Code After Timeout on write() from Asynchronous Publisher

When using an asynchronous publisher, if write() times out, it will mistakenly return DDS_RETCODE_ERROR instead of the correct code, DDS_RETCODE_TIMEOUT.

[RTI Issue ID CORE-2016, Bug # 11362]

26

Known Issues

4.8Incorrect Content Filtering for Valuetypes and Sparse Types

Content filters may not filter correctly if (a) the type is a valuetype or sparse type using inheri- tance and (b) the filters refer to members of a derived class.

This issue exists for Topics using DynamicData type support. It may also affect filtering of valu- etypes using the .NET1 or C APIs, or CORBA-compatible C++ type plugins.

[RTI Issue ID CORE-2949, Bug # 12606]

4.9Code Generation for Inline Nested Structures, Unions, and Valuetypes not Supported

Code generation for inline nested structures, unions, and valuetypes is not supported. For example, rtiddsgen will produce erroneous code for these structures:

IDL:

struct Outer {

short outer_short; struct Inner {

char inner_char; short inner_short;

} outer_nested_inner;

};

XML:

<struct name="Outer">

<member name="outer_short" type="short"/> <struct name="Inner">

<member name="inner_char" type="char"/> <member name="inner_short" type="short"/>

</struct>

</struct>

[RTI Issue ID CODEGEN-54, Bug # 9014]

4.10.NET Code Generation for Multi-dimensional Arrays of Sequences not Supported

The .NET code generated by rtiddsgen for multi-dimensional arrays of sequences is not correct and will not compile.

For example:

struct MyStruct { sequence<short, 4> m1[3][2];

};

[RTI Issue ID CODEGEN-376, Bug # 13088]

4.11Memory Leak in Applications using TCP Transport in Asymmetric Mode

If an application uses the TCP transport in asymmetric mode (server_bind_port = 0), a memory leak may occur. The size of the memory leak depends on the number of TCP connections opened by the transport and the value of the transport property parent.message_size_max.

[RTI Issue ID COREPLG-63, Bug # 14313]

1. RTI Connext .NET language binding is currently supported for C# and C++/CLI.

27

Known Issues

4.12Issues with Dynamic Data

❏The conversion of data by member-access primitives (get_X() operations) is limited when converting to types that are not supported on all platforms. This limitation applies when converting to a 64-bit long long type (get_longlong() and get_ulonglong() operations) and a 128-bit long double type (get_longdouble()). These methods will always work for data members that are actually of the correct type, but will only support conversion from values that are stored as smaller types on a subset of platforms. Conversion to 64-bit long longs from a 32-bit or smaller integer type is supported on all Windows, Solaris, and Linux architectures, and any additional 64-bit architectures. Conversion to 128-bit long doubles from a float or double is only supported on Solaris SPARC architectures.

[RTI Issue ID CORE-2986, Bug # 12647]

❏DynamicData cannot handle a union with a discriminator that is set to a value which is not defined in the type.

[RTI Issue ID CORE-3142, Bug # 12855]

❏DynamicData may have problems resizing variable-size members that are >= 64k in size. In this case, the method (set_X() or unbind_complex_member()) will fail with the error: "sparsely stored member exceeds 65535 bytes." Note that it is not possible for a member of a sparse type to be >= 64k.

[RTI Issue ID CORE-3177, Bug # 12897]

❏Topics of DynamicData types that contain bit fields are not supported by rtiddsspy. [RTI Issue ID CORE-3949, Bug # 13949]

❏DynamicData does not support out-of-order assignment of members that are longer than 65,535 bytes. In this situation, the DynamicData API will report the following error:

sparsely stored member exceeds 65535 bytes

For example:

struct MyStruct { string<131072> m1;

string<131072> m2; };

With the above type, the following sequence of operations will fail because m2 is assigned before m1 and has a length greater than 65,535 characters.

str = DDS_String_alloc(131072); memset(str, 'x', 131072); str[131071]= 0; DDS_DynamicData_set_string(

data, "m2", DDS_DYNAMIC_DATA_MEMBER_ID_UNSPECIFIED, str); DDS_DynamicData_set_string(

data, "m1", DDS_DYNAMIC_DATA_MEMBER_ID_UNSPECIFIED, str);

If member m1 is assigned before m2, the sequence of operations will succeed.

[RTI Issue ID CORE-3791, Bug # 13745]

28

Custom Supported Platforms

5 Custom Supported Platforms

Table 5.1 lists additional target libraries available with Connext, for which RTI offers custom sup- port. If you are interested in using one of these platforms, please contact your local RTI represen- tative or email sales@rti.com.

Table 5.1 Custom Supported Platforms

	Operating System		CPU	Compiler	RTI Architecture
					Abbreviation
	INTEGRITY	INTEGRITY 5.0.11	PPC8349	GHnet2 TCP/IP stack	ppc8349Inty5.0.11.mds8349
		Mistral Linux Kernel	ARMv7	Sourcery G++ Lite 2009q3-	armv7leLinux2.6gcc4.4.1
		2.6.32		67 gcc 4.4.1
		Red Hat Enterprise		gcc3.4.6	i86Linux2.6gcc3.4.6
			x86
				Sun Java Platform Standard
		Linux 5.1			i86Linux2.6gcc3.4.6jdk
				Edition JDK 1.5 and 1.6
		Red Hat Enterprise	Pentium	gcc 4.2.1	i86Linux2.6gcc4.2.1
				Sun Java Platform Standard
		Linux 5.2 (2.6 kernel)	class		i86Linux2.6gcc4.2.1jdk
				Edition JDK 1.6
		Red Hat Enterprise
		Linux 6 for IBM	POWER7	gcc 4.4.4	power7Linux2.6gcc4.4.4
		POWER7 Servers
		(2.6.32-70.el.ppc64)
	Linux
				gcc 4.1.2	i86RedHawk5.1gcc4.1.2
		RedHawk Linux 5.1	x86
				Sun Java Platform Standard	i86RedHawk5.1gcc4.1.2jdk
				Edition JDK 1.5 and 1.6
		RedHawk Linux 5.4	Pentium	gcc 4.2.1	i86RedHawk5.4gcc4.2.1
				Sun Java Platform Standard
		(2.6 kernel)	class		i86RedHawk5.4gcc4.2.1jdk
				Edition JDK 1.6
		RedHawk Linux 6.0	x64	gcc 4.4.5	x64Linux2.6gcc4.4.5
		Wind River Linux 3.0.3
		(2.6 kernel)
		Note: This platform is	Pentium	gcc 4.3.2	i86WRLinux2.6gcc4.3.2
		only available as a	class
		Custom Target Library
		(CTL). See Section 5.

6 Experimental Features

Experimental features are used to evaluate potential new features and obtain customer feedback. They are not guaranteed to be consistent or supported and they should not be used in produc- tion.

The APIs for experimental features use the suffix _exp to distinguish them from other APIs. For example:

const DDS::TypeCode * DDS_DomainParticipant::get_typecode_exp( const char * type_name);

In the API Reference Documentation1, experimental APIs are marked with <<experimental>>.

29

Experimental Features

Experimental features are clearly documented as such in the Core Libraries and Utilities What’s New document or the Release Notes document of the component in which they are included, as well as in the component’s User’s Manual.

Disclaimers

❏The experimental feature APIs may be only available in a subset of the supported lan- guages and for a subset of the supported platforms.

❏The names of experimental feature APIs will change if they become officially supported. At the very least, the suffix, _exp, will be removed.

❏Experimental features may or may not appear in future product releases.

❏Experimental features should not be used in production.

Please submit your comments and suggestions about experimental features to support@rti.com or via the RTI Customer Portal (https://support.rti.com/).

1. API reference documentation is provided in both HTML and PDF formats for all supported languages.

30
